Air Louvers 1500AHR hurricane-rated Y-Blade louver for commercial doors

Air Louvers 1500AHR Series Hurricane-Rated Y-Blade Louvers

$667.77
Request a Quote

Air Louvers 1500AHR Series Hurricane-Rated Y-Blade Louvers are designed for exterior commercial door openings that require ventilation, security, and severe windstorm performance. The inverted split “Y” blade design includes a welded security grille and thru-bolt construction, making this louver a practical option for hurricane-rated and high-abuse door applications.

Product details:

  • Hurricane-rated commercial door louver series

  • Inverted split “Y” blade design

  • Designed for severe windstorm applications

  • Meets up to 350 ft-lb impact rating

  • Florida Building Code approved

  • 40% free area

  • Non-vision louver design

  • 1" blade spacing

  • 18-gauge CRS frame and blades

  • 12-gauge security grille

  • Security grille welded to the interior and exterior of the louver

  • 13/16" square grille openings, 1" on center

  • Two-piece thru-bolt louver construction

  • Designed for 1-3/4" doors

  • Door cutout equals order size

  • Zinc-plated CRS base with powder coat finish for exterior corrosion resistance

  • Standard mineral bronze finish, with additional powder coat finishes available depending on selection

  • Optional insect screen or bird screen may be available

  • Suitable for retrofit, replacement, facility maintenance, and new construction projects

  • Available through SHP by quote

Testing and approvals may include:

  • Severe windstorm approved louver

  • Florida Building Code Approval File #FL13341

  • ASTM E330

  • ASTM E1996

  • ANSI A250.13

  • TAS 201

  • TAS 202

  • TAS 203

  • ASTM E1886

Common applications:

  • Hurricane-rated exterior doors

  • Commercial hollow metal doors

  • Coastal facilities

  • Schools and universities

  • Healthcare facilities

  • Government and municipal buildings

  • Industrial facilities

  • Utility and mechanical room doors

  • High-abuse or security-sensitive openings

Not sure which louver is right for your opening? SHP can help confirm the correct Air Louvers 1500AHR louver based on your door type, opening size, windstorm requirements, ventilation needs, finish, code requirements, and facility application.
